DC engine with DAYTON 42136D gearbox

The Dayton Model 42136D Geared DC Motor is a speed reducer motor designed for industrial and domestic applications. This high-quality, American-made engine has outstanding technical specifications that make it a suitable choice for a variety of projects and machinery.

Technical Specifications:

- Model: 42136D
- Engine power: 1/8 horsepower
- Reduction ratio: 90:1 (RATIO / RELACION / RAPPORT)
- Torque: 59 inch-pounds / 6.7 Nm (TORQUE / PAR / COUPLE)
- Maximum current: 1.3 amp
- Insulation class: Class 1
- Working environment temperature: maximum 40 degrees Celsius
- Service type: CONTINUOUS DUTY

Features:

- Made in: USA
- Input power: 1.5V
- Application: suitable for use in various reducer systems and industrial devices that require a high torque DC motor.
- Insulation : It has a high insulation class that guarantees the safety and longevity of the motor.
- Operating temperature: optimal performance in ambient temperatures up to 40 degrees Celsius
